Delta DVS-328R02-8SFP Managed Rack-Mount Ethernet Switch

PRODUKTPARAMETER

  • IPv6, DHCP/BootP, and IP/MAC binding for easy network management
  • Advanced VLAN and fast ring redundancy technologies
  • Industrial protocol compatibility (EtherNet/IP, MODBUS TCP, Profinet)
  • Security and monitoring with ACL, MAC filtering, SFP DDM, and alerts
Beschreibung
FAQs
Angebot anfordern

Beschreibung

PRODUKTMERKMALE

The Delta DVS-328R02-8SFP is a managed rack-mount Ethernet switch designed for industrial and enterprise networks. It supports IPv6, DHCP/BootP, and port-based IP/MAC binding, simplifying large-scale IP management.

The switch features advanced VLAN management including Q-in-Q, MAC-based, IP subnet-based, and VLAN isolation, along with ONE RING/ONE CHAIN redundancy and STP/RSTP/MSTP for fast network self-healing under 20ms.

Industrial protocol support includes EtherNet/IP, MODBUS TCP, Profinet, and CC-Link IE. Security and monitoring features include ACL, port MAC filtering, USB configuration, SFP DDM diagnostics, RMON groups, and automated alerts.

TECHNISCHE DATEN

一、Ports

CategoryArtikelSpezifikation
Fast EthernetRJ45 Ports20 × 10/100Base-T(X), Auto MDI/MDI-X, Auto-negotiation & Speed Detection
Fast Ethernet ComboRJ45 Ports4 × 10/100Base-T(X), Auto MDI/MDI-X, Auto-negotiation & Speed Detection
SFP Ports4 × 100Base-SFP
Gigabit Ethernet ComboRJ45 Ports4 × 10/100/1000Base-T, Auto MDI/MDI-X, Auto-negotiation & Speed Detection
SFP Ports4 × 100/1000Base-SFP
Control PortUSBUSB B-Type Connector
Digital Input (DI)Spezifikation1 × group, 0~+5V = OFF, +11~30V = ON, Max Current 6mA
Digital Output (DO)Spezifikation1 × dry contact, Max 2A @ 24VDC
Reset ButtonQuantity1 × group

二、Performance

CategoryArtikelSpezifikation
Switching CapacityPerformance12.8Gbps, Line-rate, Non-blocking
Forwarding RatePerformance19 Mpps
MAC Address TableCapacity16K
Packet BufferSize1.5M bits
IGMP Multicast GroupsCapacity256
Max VLANsCapacity255
QoSPriority Queues8
DHCP HostsCapacity1,275 IP addresses
Jumbo FrameSize9,216 Bytes

三、Network Management

CategoryArtikelSpezifikation
Management FeaturesProtocols/FunctionsSTP/RSTP/MSTP, LACP, QoS, IGMP Snooping v1/v2/v3, IGMP Query v1/v2, GARP, GMRP, VLAN, VLAN Q-in-Q, VLAN unaware, SSH, DNS, HTTP, HTTPS, RADIUS, TACACS+, SNMP v1/v2c/v3, SNMP Traps, TFTP, RMON, LLDP, BootP Server/Client, DHCP Server/Client, DHCP L2 Relay, DHCP Relay Option 82, DHCP Option 66/67, RARP, Telnet, Syslog, SMTP, SNTP Server/Client, IPv6, MODBUS TCP, EtherNet/IP
User SecurityAuthenticationMAC filtering, HTTPS, SSH, 802.1x, TACACS+, SNMP v3
Configuration InterfaceSupported ToolsWeb Browser, Cisco-like Telnet CLI, USB Local Console, SNMP, MODBUS TCP, IEXplorer Utility
MIBSupported TypesMIB II, Bridge MIB, SNMP MIB, Ether-like MIB, Q-Bridge/P-Bridge MIB, IF MIB, Traceroute MIB, TCP MIB, UDP MIB, IP MIB, RMON Group 1,2,3,9, Delta Private MIB

四、Power Requirements

CategoryArtikelSpezifikation
Input VoltageLV2 × 36~72VDC (Tested @ 36~60VDC)
HV1 × 85~264VAC / 88~370VDC (Tested @ 100~240VAC)
Max Input CurrentLV/HV0.75A / 1.2A
Overcurrent ProtectionFeaturesBuilt-in, Max 8A
Reverse PolarityProtectionBuilt-in (VDC input)

五, Mechanical

CategoryArtikelSpezifikation
EnclosureMaterialIP40 Rugged Metal
DimensionsSize44 mm (H) × 440 mm (W) × 257 mm (D)
Weight4,950 g
MountingMethod19″ Rack-mount & Wall-mount

六, Environment

CategoryArtikelSpezifikation
Operating Temp-25℃ ~ 70℃ (-13℉ ~ 158℉)
Storage Temp-40℃ ~ 85℃ (-40℉ ~ 185℉)
Operating Humidity5% ~ 95% (non-condensing)

七, Certification

CategoryArtikelSpezifikation
Safety StandardUL 60950-1, IEC 60950-1, CCC
EMIFCC 47 CFR Part 15 Subpart B Class A, IEC 61000-6-4, EN 55022(CISPR 22), EN 55032
EMSIEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, IEC 61000-4-29
ShockIEC 60255-21-2
Free FallIEC 60068-2-32
VibrationIEC 60068-2-6
Hi-Pot1.5KV
