The Delta DVP-10PM Series emphasizes high-speed execution with LD instruction at 0.1375 μs and MOV instruction at 2.1 μs.
Supports 2/3/4/5/6-axis linear interpolation motion control, 8 sets of high-speed capture (marking, frequency measurement), comparison output, and bagging alignment functions for precise motion control.
DVP10PM00M features high-precision PWM output at 200kHz with 0.3% resolution, 24 I/O points expandable up to 256 points, program capacity of 64k steps, and 10k data registers.
Equipped with 4 differential outputs at 1MHz for accurate motion control, and built-in RS-232 and RS-485 communication ports compatible with MODBUS ASCII/RTU protocols.
Built-in 6 sets of high-speed counters and hardware digital filters for counting applications
Single-axis motion control function (1-stage speed, 2-stage speed, hand wheel input)
Electronic gear function
APPLICATION FIELDS
3-Axis Servo Positioning
Engraving Machine
High-Speed Winding Machine
Semiconductor Die Bonding Machine
MOTION CONTROL FUNCTION
Product Name
Power Supply
Output Type
Input
Output
Model
International Standard
General Motion Controller
100-240VAC
Built-in 1MHz Pulse Output
16
16
DVP1PM00DY
CE, UL
Professional Motion Controller
100-240VAC
Built-in 500KHz Pulse Output
8
8
DVP2PM00DT
CE, UL
PM Expansion Module
–
Built-in 500KHz Pulse Output
–
–
DVP2PM00M
CE, UL
Module Type
Function Description
Corresponding Model
DVP-PM Module Card
Ethernet/CANopen Communication Module
DVP-PMCCM
DVP-PM Memory Card
Data Backup Memory Card (64K words)
DVP-PMCM
FAQs
Which Delta power supply products do you offer?
As a trade-and-manufacturing integrated company, we offer a full range of Delta power supplies, including switching power supplies, industrial power modules, and DC regulated power supplies, suitable for industrial automation and various electronic equipment.
Can the products be customized?
Yes. We provide customized solutions based on customer requirements, including voltage, power, and functional extensions, with professional technical support to ensure feasibility.
How are the products shipped?
We ship via reliable logistics and courier services, offering full tracking to ensure the products reach customers safely and on time.
What is the ordering process?
The process is simple: select the model → submit requirements → confirm the solution → arrange payment → delivery and technical guidance. We provide full support to ensure each step is completed smoothly.
What after-sales services are included?
We provide original manufacturer warranty, spare parts supply, operation guidance, maintenance, and troubleshooting services to ensure Delta power supplies operate stably and reliably.
