Delta 16-Channel Digital Output Expansion Module – EtherCAT R1-EC7062D0

PRODUCT PARAMETERS

  • Sixteen digital output channels for precise EtherCAT control
  • Compatible with E-BUS power module for flexible system integration
  • Enhances scalability and simplifies wiring in automation systems
  • Delivers high-speed, stable, and accurate digital output performance
Description
FAQs
Request A Quote

Description

PRODUCT FEATURES

The Delta EtherCAT 16-Channel Digital Output Expansion Module (R1-EC7062D0) provides sixteen digital output channels for precise control of remote digital signals via an EtherCAT master station.

When paired with an E-BUS power module, the R1-EC7062D0 enables reliable and flexible digital signal control across distributed automation systems.

This expansion module enhances system scalability, simplifies wiring, and ensures high-speed, stable communication for industrial automation applications.

Designed for EtherCAT networks, the module seamlessly integrates with master stations, delivering accurate and responsive digital output performance.

TECHNICAL SPECIFICATIONS

No.DescriptionNo.Description
APort 1DPort 1 IO signals
BPort 0EY08~Y15 display (upper/lower)
CY00~Y07 display (upper/lower)FPower indicator LED

Label Description (*R1-EC70202D0 / R1-EC72C2D0)

Port 0 LabelDescriptionPort 1 LabelDescription
GND*Port 0 power groundGNDPort 1 power ground
24V**Port 0 power 24V input––
Y00Digital output 0Y08Digital output 8
Y01Digital output 1Y09Digital output 9
Y02Digital output 2Y10Digital output 10
Y03Digital output 3Y11Digital output 11
Y04Digital output 4Y12Digital output 12
Y05Digital output 5Y13Digital output 13
Y06Digital output 6Y14Digital output 14
Y07Digital output 7Y15Digital output 15

Product Specifications (Four Models Comparison)

ItemR1-EC7062D0R1-EC70E2D0R1-EC70A2D0R1-EC70F2D0
Circuit Type–Transistor (MOSFET)––
Signal TypeSINK–SOURCE–
Rated Voltage24 Vdc24 Vdc24 Vdc24 Vdc
Terminal Input Current––––
Terminal Output CurrentMax 0.5A–Max 0.25A–
Open Wire Function×√×√
E-bus Current Draw120 mA––200 mA
Response / Operating Frequency––1 KHz–
Switching Unit (OFF→ON)140 μs––160 μs
Switching Unit (ON→OFF)150 μs––110 μs
Noise ImmunityShared for all models:ESD (IEC 61131-2, IEC 61000-4-2): 8KV Air DischargeEFT (IEC 61131-2, IEC 61000-4-4): Power Line 2KV; Communication I/O 1KVRS (IEC 61131-2, IEC 61000-4-3): 80MHz ~ 1GHz, 10 V/m
Operating EnvironmentShared for all models:Operating temp: 0°C ~ 50°C; Storage temp: -20°C ~ 70°C
WeightShared for all models:Approx. 60 g (0.13 lb)
Protection RatingShared for all models:IP20
Mounting MethodShared for all models:DIN rail
