PRODUCT PARAMETERS

Compact 60 mm housing for space-saving installation
High-resolution LCD display for clear temperature monitoring
Reduced development time and system cost
Enhanced temperature control performance

REQUEST A QUOTE

Description

FAQs

Request A Quote

Description

PRODUCT FEATURES

The Delta DTK Series temperature controller is designed to significantly reduce development time and overall system cost while enhancing temperature control performance.

With a compact 60 mm housing, it enables space-efficient panel installation without compromising functionality.

A high-resolution LCD display ensures clear and readable temperature status under various operating environments and conditions.

TECHNICAL SPECIFICATIONS

Item	Specifications
Input Power	DC 24V, isolated switching power supply
Operating Voltage Range	Rated voltage 90–110%
Power Consumption	Max. 10W + 3W × number of connected DTC2000 units (up to 7 units)
Input Sensors	Thermocouples: K, J, T, E, N, R, S, B, L, U, TXKRTDs: PT100, JPT100, Cu50, Ni120
Sampling Rate	Thermocouple or RTD: 1.0 s / all inputs
Control Method	PID, Programmable PID, Manual, ON/OFF
Output Options (Optional)	Relay output: SPST, max 250V AC, 3A resistive loadVoltage pulse output: DC 12V, max 40mACurrent output: DC 4–20mA (load impedance < 500Ω)Analog voltage output: 0–10V (load impedance > 1,000Ω)
Output Functions	Selectable control output, alarm output, or proportional output (proportional output applies only when OUT1/OUT2 are linear voltage or current outputs)
