Delta VFD-C200 Series Compact High-End Vector Inverter
PRODUCT PARAMETERS
- Energy-saving: reduces power consumption efficiently
- High performance: precise vector control for multiple motor types
- Durable design: long-life components with enhanced protection
- Flexible integration: supports MODBUS and CAN bus communication
Description
FAQs
Request A Quote
Description
PRODUCT FEATURES
The Delta VFD-C200 Series is a new generation compact high-end vector inverter designed to deliver precise motor control for a wide range of industrial applications. Its innovative anti-dust and heat dissipation design ensures reliable performance even in harsh environments.
Equipped with advanced vector control, the VFD-C200 supports multiple motor control modes and offers high flexibility for different industrial applications. The series also integrates PG card compatibility for closed-loop vector control and strong open-loop vector performance.
With a focus on durability, the VFD-C200 features long-life components and enhanced environmental protection. Standard MODBUS and CAN bus communication capabilities allow easy integration into industrial automation systems, ensuring efficient operation and reduced downtime.
APPLICATION FIELDS
| Application Areas | ||
|---|---|---|
| Food Packaging Machine | Conveyor Equipment | Textile Machine |
| Woodworking Machine | Fan | Water Pump |
TECHNICAL SPECIFICATIONS
| 230V | Frame | Model VFD-CB2_A- | Single-phase A0 (Frame) | Single-phase A0 (Frame) | Single-phase A0 (Frame) | Single-phase A0 (Frame) | Three-phase A0 (Frame) | Three-phase A0 (Frame) | Three-phase A0 (Frame) | Three-phase A0 (Frame) | Three-phase A0 (Frame) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Frame No. | 004 | 007 | 015 | 022 | 004 | 007 | 015 | 022 | 037 | ||
| Output – Normal Load | Applicable Motor Power (kW) | 0.4 | 0.75 | 1.5 | 2.2 | 0.4 | 0.75 | 1.5 | 2.2 | 3.7 | |
| Applicable Motor Power (HP) | 0.5 | 1 | 2 | 3 | 0.5 | 1 | 2 | 3 | 5 | ||
| Rated Output Capacity (kVA) | 1.2 | 2.0 | 3.2 | 4.4 | 1.2 | 2.0 | 3.2 | 4.4 | 6.8 | ||
| Rated Output Current (A) | 3 | 5 | 8 | 11 | 3 | 5 | 8 | 11 | 17 | ||
| Overload Tolerance | (Uniform) 120% of rated output current for 1 min; 160% for 3 sec | ||||||||||
| Maximum Output Frequency (Hz) | (Uniform) 600.00Hz | ||||||||||
| Carrier Frequency (kHz) | (Uniform) 2~15kHz (Factory setting: 8kHz) | ||||||||||
| Output – Heavy Load | Rated Output Capacity (kVA) | 1.1 | 1.9 | 2.8 | 4.0 | 1.1 | 1.9 | 2.8 | 4.0 | 6.4 | |
| Rated Output Current (A) | 2.8 | 4.8 | 7.1 | 10 | 2.8 | 4.8 | 7.1 | 10 | 16 | ||
| Overload Tolerance | (Uniform) 150% of rated output current for 1 min; 180% for 3 sec | ||||||||||
| Maximum Output Frequency (Hz) | (Uniform) 300.00Hz | ||||||||||
| Carrier Frequency (kHz) | (Uniform) 2~15kHz (Factory setting: 2kHz) | ||||||||||
| Input | Input Current (A) Normal Load | 7.2 | 12 | 15.7 | 22 | 3.9 | 6.4 | 12 | 16 | 20 | |
| Input Current (A) Heavy Load | 6.7 | 11.5 | 14 | 20 | 3.6 | 6.1 | 11 | 15 | 18.5 | ||
| Rated Voltage/Frequency | (Uniform) Single-phase/Three-phase AC 200V–240V (-15%~+10%), 50/60Hz | ||||||||||
| Operating Voltage Range | (Uniform) 170~265Vac | ||||||||||
| Allowable Power Frequency Variation | (Uniform) 47~63Hz | ||||||||||
| Cooling Method | Natural Air Cooling | Forced Air Cooling | – | – | Natural Air Cooling | – | – | Forced Air Cooling | – | ||
| Brake Chopper | (Uniform) Built-in |
| 460V | Frame | Model VFD___CB43A___ | Frame No. | 007 | 015 | 022 | 037 | 040 | 055 | 075 |
|---|---|---|---|---|---|---|---|---|---|---|
| Output – Normal Load | Applicable Motor Power (kW) | 0.75 | 1.5 | 2.2 | 3.7 | 4.0 | 5.5 | 7.5 | ||
| Applicable Motor Power (HP) | 1 | 2 | 3 | 5 | 5.5 | 7.5 | 10 | |||
| Rated Output Capacity (kVA) | 2.4 | 3.2 | 4.8 | 7.2 | 8.4 | 10 | 14 | |||
| Rated Output Current (A) | 3.0 | 4.0 | 6.0 | 9.0 | 10.5 | 12 | 18 | |||
| Overload Tolerance | Uniform | 120% of rated output current for 1 min; 160% for 3 sec | ||||||||
| Maximum Output Frequency (Hz) | Uniform | 600.00Hz | ||||||||
| Carrier Frequency (kHz) | Uniform | 2~15kHz (Factory setting: 8kHz) | ||||||||
| Output – Heavy Load | Rated Output Capacity (kVA) | 2.3 | 3.0 | 4.5 | 6.5 | 7.6 | 9.6 | 14 | ||
| Rated Output Current (A) | 2.9 | 3.8 | 5.7 | 8.1 | 9.5 | 11 | 17 | |||
| Overload Tolerance | Uniform | 150% of rated output current for 1 min; 180% for 3 sec | ||||||||
| Maximum Output Frequency (Hz) | Uniform | 300.00Hz | ||||||||
| Carrier Frequency (kHz) | Uniform | 2~15kHz (Factory setting: 2kHz) | ||||||||
| Input | Input Current (A) Normal Load | 4.3 | 5.9 | 8.7 | 14 | 15.5 | 17 | 20 | ||
| Input Current (A) Heavy Load | 4.1 | 5.6 | 8.3 | 13 | 14.5 | 16 | 19 | |||
| Rated Voltage/Frequency | Uniform | Three-phase AC 380V~480V (-15%~+10%), 50/60Hz | ||||||||
| Operating Voltage Range | Uniform | 323~528Vac | ||||||||
| Allowable Power Frequency Variation | Uniform | 47~63Hz | ||||||||
| Cooling Method | Natural Air Cooling | – | – | – | – | Forced Air Cooling | – | |||
| Brake Chopper | Uniform | Built-in | ||||||||
| Note | *… indicates models -20/-21/-211, etc. |
