Delta DOP-103BQ Basic HMI for Industrial Applications

PRODUCT PARAMETERS

  • 4.3-inch 16:9 TFT display with 65,536 colors for clear process visualization
  • Cortex-A8 800MHz CPU with 256 MB RAM and ROM for stable performance
  • Multiple connectivity options: 2 COM ports, 1 expansion COM, USB Host/Client
  • CE/UL certified, operational 0–50℃, storage -20–60℃, durable buttons over 1,000,000 presses
Description
FAQs
Request A Quote

Description

PRODUCT FEATURES

The Delta DOP-103BQ is a 4.3-inch basic human machine interface (HMI) designed for industrial automation with a 16:9 display aspect ratio.

It features a 480×272 TFT display capable of showing 65,536 colors, providing clear visualization of process data and machine status.

Powered by a Cortex-A8 800MHz CPU with 256 MB RAM and 256 MB ROM, it ensures smooth operation and reliable performance for basic control tasks.

Connectivity options include two physical COM ports, one expansion COM port, USB Host, and USB Client, allowing flexible integration with Delta PLCs and other industrial equipment.

CE and UL certified, the DOP-103BQ operates in temperatures from 0℃ to 50℃ and can be stored from -20℃ to 60℃. The front panel buttons are durable for over 1,000,000 presses.

TECHNICAL SPECIFICATIONS

ItemSpecification
Display4.3” TFT, 480×272 resolution, 65,536 colors
CPUCortex-A8 800 MHz
RAM256 MB
ROM256 MB
Serial Ports2 built-in COM, 1 expansion COM
USBUSB Host, USB Client
CertificationCE / UL safety standards
Operating Temperature0℃ ~ 50℃
Storage Temperature-20℃ ~ +60℃
Key LifeOver 1,000,000 presses

FAQs
