Delta DVS-008I00 Fast Ethernet Switch — 8-Port

PRODUCT PARAMETERS

  • Dual 12–48 VDC redundant power input
  • Supports 8 Fast Ethernet ports
  • Industrial protocol compatibility (EtherNet/IP, Profinet, CC-Link IE, DNP 3.0)
  • Reliable operation for enterprise and industrial networks
Description
FAQs
Request A Quote

Description

PRODUCT FEATURES

The Delta DVS-008I00 is a reliable 8-port Fast Ethernet switch designed for industrial and enterprise networks. It features dual 12–48 VDC redundant power inputs for uninterrupted operation.

The switch supports industrial protocols including EtherNet/IP, Profinet, CC-Link IE, and DNP 3.0, allowing seamless integration with automation and control systems for stable and efficient network performance.

TECHNICAL SPECIFICATIONS

CategoryParameterSpecification
StandardProtocolIEEE 802.3 10Base-T
IEEE 802.3u 100Base-T(X) and 100Base-FX
IEEE 802.3x Flow Control
IEEE 802.1p Class of Service, Priority Protocols
Switching TechnologyTypeStore and Forward
Flow ControlIEEE 802.3x Full-Duplex Flow Control, Half-Duplex Backpressure Flow Control
InterfaceEthernetFast Ethernet
RJ45 Ports8 × 10/100Base-T(X), Auto MDI/MDI-X, Auto-negotiation and Link Speed Detection
PerformanceSwitching Capacity1.6 Gbps, Linear, Non-blocking
Packet Forwarding Rate2.4 Mpps
MAC Address Table8K
Packet Buffer Size1M bits
Power RequirementsInput Voltage12 ~ 48 VDC, 1 terminal block
Maximum Input Current0.18 A
MechanicalHousingIP40 Reinforced Aluminum Alloy
Dimensions (H × W × D)145.3 mm × 45 mm × 108.7 mm
Weight300 g
MountingIndustrial DIN Rail & Wall Mount
EnvironmentOperating Temperature-10℃ ~ 60℃ (14℉ ~ 140℉), tested @ -25℃ ~ 70℃ (-13℉ ~ 158℉)
Storage Temperature-40℃ ~ 85℃ (-40℉ ~ 185℉)
Operating Humidity5% ~ 95% (Non-condensing)
CertificationSafetyUL 508, EN 60950-1, IEC 61131-2
EMIFCC 47 CFR Part 15 Subpart B Class A, IEC 61000-6-4, EN 55022
EMSIEC 61000-6-2
Industrial Environment TestsLow TemperatureIEC 60068-2-1
High TemperatureIEC 60068-2-2
HumidityIEC 60068-2-30
ShockIEC 60255-21-2
Free FallIEC 60068-2-32
VibrationIEC 60068-2-6
Hi-Pot1.5 KV
