Delta DX-2100RW-WW IIoT Router / 3G Router / Cloud Router
PRODUCT PARAMETERS
- Cloud-connected IIoT router with secure two-way data acquisition
- UMTS/HSPA+ 3G support with automatic dialing and reconnect functionality
- Dual RS-232/RS-485 serial ports and LAN ports for versatile device connectivity
- Advanced firewall, email alerts, network diagnostics, and mobile monitoring support
Description
FAQs
Request A Quote
Description
PRODUCT FEATURES
The Delta DX-2100RW-WW IIoT Router is designed for cloud-connected data acquisition, enabling secure two-way data transfer between users and industrial devices without the need for an additional VPN server.
It supports standard industrial protocols including MODBUS TCP and MODBUS RTU/ASCII for seamless integration with automation systems.
Equipped with UMTS/HSPA+ 3G technology, it supports frequencies 800/850, 900, AWS1700, 1900, and 2100 MHz while remaining backward compatible with GSM/GPRS/EDGE 2G networks. HSPA+ data rates reach up to 21.6 Mbps download and 5.76 Mbps upload.
Automatic dialing parameter matching and reconnect functionality ensures continuous network operation. Dual serial ports (RS-232 and RS-485) and LAN ports provide flexible device connectivity.
NTP server synchronization and built-in RTC maintain accurate device timing. The integrated firewall includes SPI, DoS prevention, NAT, port triggering, port mapping, IP filtering, MAC filtering, and URL filtering.
It supports multiple network protocols including TCP/IP, UDP, ICMP, DHCP, HTTP, DNS, and SSH, along with scheduled task management, configuration export/import, network traffic statistics, and fault diagnostics.
The router offers verification with subordinate devices, email alert functions with user-defined conditions, and online monitoring via Android and iOS mobile applications.
TECHNICAL SPECIFICATIONS
Technical Specifications
1. Standards / Protocols
| Parameter | Specification |
|---|---|
| Cellular | GSM / GPRS / EDGE / UMTS / HSPA+ |
| Ethernet | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-T(X) |
2. Interfaces
| Parameter | Specification |
|---|---|
| 3G | GSM / GPRS / EDGE / UMTS / HSPA+ |
| Antenna | 1 Omni-directional 2.5 dBi, SMA (male) connector, 3 m cable with magnetic base |
| Fast Ethernet Ports | RJ45 Ports:WAN: 1 × 10/100Base-T(X), auto MDI/MDI-X, auto negotiation and speed detection |
| Serial Communication | 1 × RS-232 DB9 (male), 1 × RS-485 DB9 (female), 15 kV isolation |
| Baud Rate | 2,400 ~ 115,200 bps |
| Data Bits | 7, 8 |
| Parity | None, Even, Odd |
| Stop Bits | 1, 2 |
| Flow Control | RTS/CTS (RS-232 only), XON/XOFF |
| RS-232 Signals | TxD, RxD, RTS, CTS, GND |
| RS-485 Signals | D+, D-, GND |
| LEDs | Device: PWR, SD, Ready, 3G, Signal StrengthRJ45: LANSerial: RS-232 RX/TX, RS-485 RX/TX |
| Reset Button | 1 set |
3. 3G Wireless RF
| Parameter | Specification |
|---|---|
| UMTS/HSPA+ Bands | 800 / 850, 900, AWS 1700, 1900, 2100 MHz |
| UMTS/HSPA+ CN Model | 900, 2100 MHz |
| GSM/GPRS/EDGE Bands | 850, 900, 1800, 1900 MHz |
4. Network Management
| Parameter | Specification |
|---|---|
| Cloud Service | DIACloud |
| Management | SSH, DNS, HTTP, TFTP, DHCP Server/Client, Telnet, Syslog, MODBUS TCP, NTP, MODBUS RTU/ASCII |
| User Security | MAC/IP/URL filtering, SSH, SPI, DoS attack prevention, Port triggering, Port mapping |
| Virtual COM Support | Windows XP, Windows Vista (32/64-bit), Windows 7 (32/64-bit) |
| Configuration Interface | Web Browser, DIACom, Android APP, iOS APP |
5. Power Requirements
| Parameter | Specification |
|---|---|
| Input Voltage | 12 ~ 48 VDC, 3-pin terminal |
| Max Input Current | 1 A |
| Overcurrent Protection | Built-in, supports up to 1.5 A |
| Polarity Protection | None |
6. Mechanical Specifications
| Parameter | Specification |
|---|---|
| Housing | IP30 rugged metal |
| Dimensions (H×W×D) | 111 × 77 × 26 mm |
| Weight | 196 g |
| Mounting | Wall-mount |
7. Environmental
| Parameter | Specification |
|---|---|
| Operating Temperature | -20℃ ~ 70℃ (-4℉ ~ 158℉) |
| Storage Temperature | -40℃ ~ 85℃ (-40℉ ~ 185℉) |
| Operating Humidity | 5% ~ 95% (non-condensing) |
8. Certifications
| Parameter | Specification |
|---|---|
| Safety Standards | UL 60950-1, EN 60950-1 (Certified Model: DX-2100RW-WW) |
| EMI | FCC 47 CFR Part 15 Subpart B Class A, EN 55022, EN 301 489-1/7/24 (Certified Model: DX-2100RW-WW) |
| EMC | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8 (Certified Model: DX-2100RW-WW) |
| Wireless Certification | EN 301 511, EN 301 908-1; FCC Part 22H, 24E, 27 (Certified Model: DX-2100RW-WW) |
