Delta DVS-G512W01-4GF Managed Switch / PoE Ethernet Power Supply
PRODUCT PARAMETERS
- Each port supports up to 30 W PoE with IEEE 802.3at/af compliance and intelligent power management.
- Advanced redundancy features with Redundancy RING/CHAIN, MRP, and STP/RSTP/MSTP for sub-30 ms network self-healing.
- Comprehensive network management and security with SNMP, QoS, VLAN, ACL, MAC filtering, and loopback detection.
- Industrial protocol compatibility with EtherNet/IP, Profinet, CC-Link IE, and DNP 3.0, plus SFP DDM diagnostics.
Description
FAQs
Request A Quote
Description
PRODUCT FEATURES
The Delta DVS-G512W01-4GF is a managed industrial Ethernet switch providing reliable PoE power for network devices.
Each port delivers up to 30 W and is fully compliant with IEEE 802.3at, while backward compatible with IEEE 802.3af devices.
Advanced PoE management intelligently matches PD device power requirements, optimizing energy efficiency and device safety.
Equipped with IPv6 support, DHCP automation, and option 82 relay, the switch simplifies network IP management and large-scale deployment.
High-level network management features include SNMP v1/v2c/v3, Redundancy RING & CHAIN protocols, MRP standard support, and STP/RSTP/MSTP for ring network redundancy, ensuring sub-30 ms self-healing.
Quality of Service (QoS), VLAN (IEEE 802.1Q, Q-in-Q), and GVRP protocols optimize traffic for time-sensitive applications, while advanced security (IEEE 802.1X, SSH, TACACS+, HTTPS, SNMPv3) protects the network.
The switch supports IEEE 802.3ad link aggregation, IEEE 1588v2 PTP time synchronization, multicast/broadcast storm control, loopback detection, ACL, MAC filtering, IGMP management, port mirroring, and SFP DDM diagnostics.
Automatic alert notifications via email, relay, Syslog, and SNMP trap ensure proactive monitoring, and the device is compatible with EtherNet/IP, Profinet, CC-Link IE, and DNP 3.0 protocols.
TECHNICAL SPECIFICATIONS
Technical Specifications
1. Standards / Protocols
| Parameter | Specification |
|---|---|
| Ethernet Standards | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-T(X)/100Base-FX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-X |
| Flow Control & Switching | IEEE 802.3x full-duplex flow control, half-duplex backpressure |
| Spanning Tree Protocols | IEEE 802.1D, 802.1w, 802.1s |
| VLAN & QoS | IEEE 802.1p Class of Service, IEEE 802.1Q VLAN Tagging, IEEE 802.1AD VLAN Q-in-Q |
| Authentication & Aggregation | IEEE 802.1X Port Authentication, IEEE 802.3ad LACP Aggregation |
| Discovery Protocol | IEEE 802.1AB Link Layer Discovery Protocol |
| Clock Sync & PoE | IEEE 1588v2, IEEE 802.3af PoE (15.4W), IEEE 802.3at PoE+ (30W) |
2. Switching Technology
| Feature | Specification |
|---|---|
| Method | Store and Forward |
3. Interfaces
| Feature | Specification |
|---|---|
| Gigabit Ethernet Ports | 8 × RJ45 10/100/1000Base-T, auto MDI/MDI-X, auto-negotiation |
| SFP Ports | 4 × 100/1000Base-SFP |
| PoE+ Pins | 1 & 2 DC +, 3 & 6 DC – |
| Control Port | RJ45 |
| Digital Output (DO) | 1 × Dry Contact, max 1A @ 24VDC |
| Reset Button | 1 set |
4. Performance
| Feature | Specification |
|---|---|
| Switching Capacity | 24 Gbps, linear, non-blocking |
| Forwarding Rate | 35.7 Mpps |
| MAC Address Table | 8K entries |
| Packet Buffer | 4 Mbits |
| IGMP Multicast Groups | 256 |
| Max VLANs | 4096 |
| QoS | 8 priority queues |
| DHCP Hosts | 253 IP addresses |
| Jumbo Frames | 9,216 Bytes |
5. Network Management
| Feature | Specification |
|---|---|
| Management Functions | STP/RSTP/MSTP, LACP, QoS, IGMP Snooping v1/v2/v3, IGMP Query v1/v2, VLAN, SSH, DNS, HTTP, HTTPS, RADIUS, TACACS+, SNMP v1/v2c/v3, SNMP Traps, TFTP, RMON, LLDP, DHCP Server/Client, DHCP Relay Option 82, Telnet, Syslog, SMTP, SNTP Client, DOS/DDOS auto prevention, MRP, MODBUS TCP |
| User Security & Authentication | MAC/IP/TCP/UDP filtering, HTTPS, SSH, 802.1x, SNMP v3 |
| Configuration Interface | Web Browser, Cisco-like Telnet CLI, RJ45 console, SNMP |
| MIB Support | MIB II, Bridge MIB, SNMP MIB, Ether-like MIB, Q-Bridge/P-Bridge MIB, IF MIB, Traceroute MIB, TCP MIB, UDP MIB, IP MIB, RMON Group 1/2/3/9, Delta Private MIB |
6. Power Requirements
| Feature | Specification |
|---|---|
| Input Voltage | 50 ~ 57 VDC, 2 × terminal blocks |
| Max Input Current | 5A (PoE), 0.26A (non-PoE) |
| Overcurrent Protection | Built-in, max 10A |
| Reverse Polarity Protection | None |
7. Mechanical Specifications
| Feature | Specification |
|---|---|
| Housing | IP30 rugged metal |
| Dimensions (H × W × D) | 154 × 96.4 × 105.5 mm |
| Weight | 1205 g |
| Mounting | DIN rail & wall-mount |
8. Environmental
| Feature | Specification |
|---|---|
| Operating Temperature | -40℃ ~ 70℃ (-40℉ ~ 158℉) |
| Storage Temperature | -40℃ ~ 85℃ (-40℉ ~ 185℉) |
| Operating Humidity | 5% ~ 95% (non-condensing) |
9. Certifications
| Feature | Specification |
|---|---|
| Safety Standards | EN 60950-1 |
| EMI | FCC 47 CFR Part 15 Subpart B Class A, EN 55022(CISPR 22) |
| EMS | EN 55024, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11 |
| Shock | IEC 60068-2-27 |
| Free Fall | IEC 60068-2-32 |
| Vibration | IEC 60068-2-6 |
| Hi-Pot | 1.5 kV |
