Delta DVS-G406W01-2GF Unmanaged PoE Ethernet Switch with 6-Port

PRODUCT PARAMETERS

  • Four 10/100/1000Base-T PoE ports supporting up to 30W per port
  • SFP ports with dual-speed 100Base-FX/1000Base-X support
  • Jumbo frame transmission up to 9,216 Bytes
  • Redundant DC power input with relay alarm and industrial protocol compatibility
Description
FAQs
Request A Quote

Description

PRODUCT FEATURES

The Delta DVS-G406W01-2GF is a reliable unmanaged 6-port PoE Ethernet switch designed to deliver stable power and data transmission. It provides four 10/100/1000Base-T PoE (PSE) ports, each supporting IEEE 802.3at standard with up to 30W output and backward compatible with IEEE 802.3af devices.

The switch features SFP ports supporting dual-speed 100Base-FX and 1000Base-X transmission, and jumbo frame support up to 9,216 Bytes for efficient data handling. It also includes dual 50–57 VDC redundant power inputs with relay alarm for power failure notifications.

Industrial protocol compatibility includes EtherNet/IP, Profinet, CC-Link IE, and DNP 3.0, enabling seamless integration with automation and monitoring systems, making it ideal for industrial and enterprise PoE networks.

TECHNICAL SPECIFICATIONS

CategoryItemSpecification
Standard / ProtocolIEEE 802.3 10Base-T—
IEEE 802.3u 100Base-T(X) and 100Base-FX—
IEEE 802.3ab 1000Base-T—
IEEE 802.3z 1000Base-X—
IEEE 802.3x Flow ControlFull-duplex flow control, half-duplex backpressure control
IEEE 802.3af PoE15.4 Watts
IEEE 802.3at PoE30 Watts
Gigabit EthernetRJ45 Ports4 × 10/100/1000Base-T, auto MDI/MDI-X, auto-negotiation & speed detection
SFP Ports2 × 100/1000Base-SFP
Function SettingsDIP SwitchSFP speed setting, power failure alarm
Digital Output (DO)Alarm Output1 dry contact, max 1A @ 24VDC
Switching Capacity12 Gbps, line rate, non-blocking
Forwarding Rate8.9 Mpps
MAC Address Table1K
Packet Buffer1M bits
Jumbo Frame9,216 Bytes
Input Voltage50 ~ 57 VDC, 2 terminal blocks
Max Input Current5A
Overload ProtectionBuilt-in, max 10A
Reverse Polarity ProtectionNone
EnclosureIP30 rugged metal
Dimensions (H × W × D)144.3 mm × 26.1 mm × 94.9 mm
Weight410g
MountingIndustrial DIN-rail & wall-mount
Operating Temperature-40℃ ~ 70℃ (-40℉ ~ 158℉)
Storage Temperature-40℃ ~ 85℃ (-40℉ ~ 185℉)
Operating Humidity5% ~ 95% (non-condensing)
Safety StandardEN 60950-1
Electromagnetic Interference (EMI)FCC 47 CFR Part 15 Subpart B Class A, EN 55022 (CISPR22)
Electromagnetic Susceptibility (EMS)IEC 61000-4-2 L3, IEC 61000-4-3 L3, IEC 61000-4-5 L3, IEC 61000-4-6 L3
