Delta AX-3 Series Motion Control CPU – High-Function General-Purpose Controller

PARAMETRI DEL PRODOTTO

  • 8-axis EtherCAT motion control with 2 ms minimum synchronization
  • IEC 61131-compliant CODESYS integrated development platform
  • Flexible I/O expansion and multiple device connectivity
  • Supports IEC 61131-3 programming languages and OPC UA server integration
Descrizione
Domande frequenti
Richiesta di preventivo

Descrizione

CARATTERISTICHE DEL PRODOTTO

8-axis EtherCAT motion controller with minimum synchronization time of 2 ms.

Integrated CODESYS development platform compliant with IEC 61131 standards, consolidating automation requirements across devices.

Supports existing AS I/O modules, reducing additional configuration costs and enabling flexible expansion.

*Multiple interfaces including Ethernet 2, RS-485, RS-232, and encoder inputs, allowing connection with various devices.

Integrated development environment allows configuration of motion axes on a single platform, offering motion control planning tools, PLCopen MC standard function blocks, E-CAM editor, positioning planning, and visualization tools.

Supports IEC 61131-3 international programming languages (FBD, LD, ST, SFC, CFC), accommodating diverse development methods.

Supports OPC UA (Server) without requiring an additional OPC UA gateway for connecting to information management systems.

APPLICATION FIELDS

Wood ProcessingPackagingPrinting
TextilePharmaceutical

SPECIFICHE TECNICHE

CategorySpecifications
Motion Control NetworkAX-308E: EtherCAT (100 Mbps)
Synchronous Axes / TimeUp to 16 axes (real + virtual + pulse axes) 8 axes / 2 ms, max 8 real axes (EtherCAT) Up to 4 pulse axes
Electronic Cam FunctionNumber of cam tables: 80 Max points per cam table: 256
Program / PerformanceProgram capacity: 8 MB Variable capacity (with power-off retention): 768 kb Variable capacity (without power-off retention): 16 MB LD instruction execution time: 5 ns Arithmetic instruction (LREAL): 36 ns
Communication InterfaceMini USB(2.0) / RS232 / RS485 x1 each 2 Ethernet ports, supporting Modbus TCP (Server + Client = 32) and EtherNet/IP (Scanner/Adapter), Scanner supports up to 8 Adapters
I/O Interface2 incremental encoder interfaces + 1 SSI absolute encoder interface 6 high-speed counters (200 kHz) 4 pulse outputs (200 kHz) Max I/O expansion: Input 8,192 bytes / Output 8,192 bytes Max expansion modules: 32 (analog: 16)
Additional FeaturesBuilt-in Micro SD slot Built-in RTC (requires CR1620 3V battery)
