Delta DVS-110W02-3SFP Managed Switch / DIN Rail Ethernet

ПАРАМЕТРЫ ПРОДУКТА

  • 7 Fast Ethernet + 3 Gigabit SFP ports with VLAN and QoS.
  • IPv6 support and MODBUS TCP for industrial monitoring.
  • STP/RSTP redundancy and advanced security.
  • IP40 housing and compatibility with EtherNet/IP, Profinet, CC-Link IE, DNP 3.0.
Описание
Вопросы и ответы
Запрос Цитировать

Описание

ХАРАКТЕРИСТИКИ ПРОДУКТА

The Delta DVS-110W02-3SFP is a DIN rail-managed industrial Ethernet switch featuring 7 Fast Ethernet ports and 3 Gigabit Combo SFP ports, designed for backbone network applications with high reliability.

It provides full L2 management including VLAN, QoS, LACP, IGMP, SNMP v1/v2c/v3, IPv6 support, neighbor discovery, and MODBUS TCP integration for industrial monitoring and control.

Advanced redundancy with STP/RSTP/MSTP, SFP DDM diagnostics, robust security (IEEE 802.1X, TACACS+, SSH, HTTPS, SNMP v3), automated alerts, and compatibility with EtherNet/IP, Profinet, CC-Link IE, and DNP 3.0 protocols ensure stable operation in extreme environments from -40℃ to 75℃.

ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ

CategoryАртикулТехнические характеристики
PortsRJ45 Ports• 10/100Base-TX, Auto MDI/MDIX, Auto Negotiation• Compatible with Gigabit Combo Interface
Gigabit Combo Interface• 10/100/1000Base-T, Auto MDI/MDIX, Auto Negotiation• 100/1000Base-SFP
Control PortLEDs• USB, Power• ALARM, PWR1, PWR2, DI1, DI2
Interface• 10/100M RJ45 (RS-232)• 10/100M RJ45 (GbE)• 10/100M (FE RJ45), LINK/ACT
Digital Input (DI)Технические характеристики• +5V = ON, 0V = OFF
Digital Output (DO)Технические характеристики• Alarm Output (DO)• Max 5A @ 24VDC
Reset ButtonQuantity• 1 set
PerformanceSwitching Capacity• 4.7Gbps, Line-rate, Non-blocking• Packet Forwarding Rate
Packet BufferSize• IGMP Multicast Groups: 1K• 256
QoSSupported Features• 8 Priority Queues• DHCP/BOOTP Hosts• 127.5 P/Bcast• Jumbo Frame: 3216 Bytes
Network ManagementSupported Protocols/FunctionsSTP/RSTP/WSTP, LACP, GARP, IGMP Snooping v1/v2/v3, IGMP Query v1/v2,DHCP Client, DHCP Relay, DHCP Filter, DHCP Option 82, DHCP Snooping,SNMP v1/v2c/v3, RMON, LLDP, Syslog, HTTP, HTTPS, TFTP, SFTP,Service, CLI, DHCPv6, DHCPv6 Relay, DHCPv6 Filter, DHCPv6 Option,Telnet, SSH, SSL, SNMP Server, IPv6, MQTT, TCP,IEEE 802.1X, RADIUS, TACACS+,MACTTP, CFDP, Link Flapping, HTTPS, SSH, SSL, TACACS+, SNMP v3
Configuration InterfaceSupported Tools• Web Browser, Cisco-like Telnet CLI, USB Local Console, SNMP,MODBUS, SNMP, EXPRESS Utility
MIBSupported Types• IEEE STD 802.1D MIB, Ethernet MIB, Bridge-Bridge MIB,IF MIB, IEEE Traps MIB, LLDP MIB, IP MIB, RMON MIB,Group 1,2,3,9, Delta Private MIB
Power RequirementsInput Voltage• 9~48V, 2 Terminal Connections
Max Input Current• 0.5A
Overload ProtectionFeatures• Built-in: Max 3A• Reverse Polarity Protection
Hold-up TimeParameter• Minimum 12ms @ 24VDC
